SB112i
| 39Hz LF Limit, High Power handling, High Efficiency |
| Low distortion, Low thermal compression |
| Laminar vents |
| Integrated locking feet |
| Designed with Cardioid Sub Arrays in mind |
OVERVIEW
The SB112i is a high efficiency, high impact sub-bass loudspeaker with exceptionally high power handling. It provides high impact, high sensitivity, low thermal compression and incredibly low distortion, even at the highest drive levels. These combined properties deliver the sonic qualities of precision and musicality.
The SB112i is one of the recommended subwoofers for use with the C coaxial series and is also well suited for use with the VC system family from RMS-Acoustics. The SB112i can be deployed in standard or cardioid configurations, with dedicated presets for each configuration, in flown, or stacked configurations.
The SB112i features one long excursion, high power handling 12” cone loudspeaker mounted in a mechanically and acoustically optimized bass reflex cabinet with laminar venting. Port turbulence is virtually eliminated, and high drive level distortion is minimized via large, flared, symmetrical laminar venting. It operates from 44 Hz to 120 Hz when flown and from 39 Hz to 100 Hz when used as a general ground support subwoofer.
The SB112i enclosure was designed with installation in mind. It features 16 integrated fly points and optional array frames that allow for mounting to ceilings and the creation of traditional and cardioid flown arrays. The compact profile allows the SB112i to fit easily under stages, up tight to ceilings, and between standard framing for flush mount installations.
The enclosure is constructed of premium birch hardwood plywood to ensure maximum acoustical and mechanical integrity. It is then coated with a weather and wear resistant textured urethane hybrid finish. Components in the front of the enclosure are protected by a steel grill made from perforated steel and lined with acoustically transparent foam. All grill and rigging components are weather and corrosion protected with a heat cured epoxy powder coated finish or zinc plating with passivation.
The optimum processed loudspeaker solution for the RMS-Acoustics SB subwoofer family are Linea Research C and M series amplifiers, with proprietary presets provided by RMS-Acoustics.
SPECIFICATIONS
| System Sensitivity (1w, 1m)^1 | 97dB | (2.9V @ 100Hz, 1W 1m) |
| Frequency Response(-10dB) | 39Hz-150Hz | 0dB point taken at 60Hz, processed |
| Frequency Response (±3dB) | 44Hz-150Hz | 0dB point taken at 60Hz, processed |
| Maximum SPL Continuous (1m)^2 | 125dB | |
| Maximum SPL Peak (1m) | 131dB | |
| Long Term Power Rating (IEC)^3 | LF | 800W Continuous, 1600W Program, 3200W Peak 100Hr |
| Long Term Power Rating (AES)^4 | LF | 1000W (2000W Peak) 2 hr |
| Maximum Input Voltage | LF | 89.5 V RMS (2 hrs), 127V Peak |
| Nominal Coverage Pattern | Omni directional, variable directivity with cardioid presets and custom modification | |
| System Crossover | Proprietary DSP via RMS-ACOUSTICS and Linea Research processing platform | |
| Transducer Specifications | SPKR-12-0007 | LF Driver - 12” low frequency cone loudspeaker with 4” voice coil, shorting ring and high performance convective cooling technology |
| Impedance | LF | 8 Ohm, Optional 4 Ohm |
| PHYSICAL: | ||
| Input Connectors | Dual Neutrik NL4MP Connectors | |
| Enclosure Materials | 15mm Birch Hardwood Ply 1.3mm layers | |
| Grill Materials | Cold Rolled Steel, Epoxy powder coat, Acoustically transparent black foam backing | |
| Finishes | Black finish (Standard) Polyurethane textured spray | |
| Additional Finishes available - See Options Below | ||
| Suspension and Mounting | Proprietary internal, captive rigging | |
| Flown Array Maximum | Maximum Array height dependent or rigging system employed. Standard and Cardiod flown arrays possible. Contact support at [email protected] to discuss further. | |
| Rigging Hardware | ||
| Dimensions | 22” W x 22” D x 14.25” H (559 mm x 559 mm x 362 mm) 14.0" H ( 356 mm) with feet removed | |
| Weight | 70 Lbs (31.8 kg) Net Shipping weight 78Lb (35.5 kg) | |
| Finish Options | -X (Weatherized), -W (White), -C (Custom Color) Upcharge applies | |
| Optional Accessories | ||
| Free field, semi anechoic conditions. To compare with half space measurements, add 6dB to maximum output specifications. | ||
| 1. Full Space, 4pi conditions | ||
| 2. Measured Maximum SPL, based on power compression observation of 3dB | ||
| 3. IEC Shaped pink noise with 6dB Crest Factor | ||
| 4. AES Standard AES2-2012, one decade pink noise with 6dB Crest factor within device’s applicable operating band, free air. Standard AES 2 hr rating are specific for low frequency transducers. | ||
